Title: Taking Back Control: Formally Modelling a Compiler Intermediate Representation for GPU Computing
When: Tuesday, 04 March 2025 at 1900 hrs (IST)
Meeting Details: Zoom link, ID: 891 6409 4870, Passcode: 082194
Abstract:
We will present our POPL 2023 work on using formal modelling
and analysis techniques to understand and fix fundamental
problems in the design of SPIR-V, a compiler intermediate
representation that is widely-used in GPU computing. An
innovation of SPIR-V is that it features special instructions
that allow information about high level control flow constructs
to be documented in its otherwise-unstructured basic
block-based representation. The idea is that compilers can
exploit this information to generate efficient GPU-specific
machine code. However, the original definitions of these
instructions and the rules that govern them were fraught with
ambiguities, preventing users of SPIR-V from understanding
their purpose and hindering their use by compiler developers.
We used the Alloy modelling language and analysis tool to build
an initial best-effort formal model of SPIR-V control flow,
after which we iteratively refined the model by cross-checking
it against official documentation, test suites and validation
tools, consulting with experts in industry to resolve
differences. Along the way we fixed numerous deficiencies in
these test suites and validation tools, and ended up with
agreement between our revised formal model and these other
sources of truth about SPIR-V. We then rewrote relevant parts
of the English language formal specification based on our
rigorous formal model, and our changes to the language have
been incorporated in the latest version of the SPIR-V
specification. As an added bonus, we devised a novel technique
for automated testing of SPIR-V compilers that uses our formal
model to generate unusual control flow graphs which are then
fleshed out into self-checking SPIR-V test cases. This led to
the discovery of numerous bugs affecting open source and
commercial SPIR-V compilers.
